Jacksonville Data Center

Jacksonville Data Center Overview

Our Jacksonville Data Center is ScaleMatrix' US-South 02 facility which was built to withstand severe weather events with 15-inch reinforced concrete walls and 2N redundancy for all critical power and cooling systems, including dual power feeds from independent grids. Jacksonville’s thriving industries of tourism, agriculture, aerospace, aviation, and life sciences are exploring AI to advance their businesses. ScaleMatrix helps these leaders remove the complexities and challenges so they can achieve their performance and efficiency goals.

KEY STATISTICS
- Power Density Supported Per Cabinet

  1 - 52kW Dynamic Density Control (DDC)
- Watts Per Square Foot

  2000+
- PUE

  1.15 – 1.2
- Cabinet Height

  45U
- Minimum Space Commitment

  1U
- Minimum Power Commitment

  1kW
- Contiguous Space Availability At Any Density

  Yes
- Additional Set Up Cost for High Density Support

  No
- Additional Set Up Time for High Density Support

  No
- Cooling Set Point (Temp) and Airflow (CFM) Guarantee

  Yes
- Real-Time & Historic Environmental Monitoring

  Yes
- Biometric or 2FA Cabinet Level Security Included

  Yes
- Cabinet Level Fire Suppression / Risk Mitigation

  Yes
- Managed Power + Real Time Reporting & Reboot

  Yes
- ScaleMatrix Hybrid Cloud Services Node

  Q4 2019
- DDoS Mitigation Services

  Yes
- Software Defined Network On-Ramp Services

  Yes (AWS, Google, Azure, IBM, Others) Megaport
- 24/7/365 Enhanced Remote Hands Support

  Yes
- BC/DR Space Availability

  Yes
CLOUD & PROFESSIONAL SERVICES
- Cloud Hosting (On Demand, IaaS, Private Cloud)

  Yes
- Multi-Tiered Storage Services (File/Block/Object)

  Yes
- Managed Backup Solutions (BaaS)

  Yes
- Managed Disaster Recovery Solutions (DRaaS)

  Yes
- Professional & Managed Service Offering

  Yes
CONNECTIVITY & FIBER
- Site Connectivity Availability

  10G
- IP Carrier Availability

  Florida LambdaRail
- Fiber Carrier Availability (Dark, Lit)

  AT&T, Cogent, Comcast, FPL, Level 3, Southern Light, TW Telecom
COMPLIANCE
- SSAE-16 SOC1 Type 2

  Yes
- SSAE-18 SOC2 Type 2

  Yes
- SSAE-18 SOC3 Type 2

  Yes
- PCI DSS V3.2 AoC and Merchant L4\SAQ C-VT Certification

  Yes
- HI-TRUST

  No
- HIPPA Compliance

  Yes
SECURITY
- 24/7 Remote Monitoring

  Yes
- Biometric Authentication

  Yes
- CCTV

  Yes
- Controlled Perimeter Access

  Yes
- Dual Authentication

  Yes
- Mantrap

  No
- On-Site Security Personnel

  Yes
DATA CENTER
- Tier Rating or Equivalent

  Tier 2
- Total Cabinet Footprint Capacity

  5,000
- Gross Area Sq. Feet

  119,961
- Year Built

  1998
- Year Renovated

  2019
- Outside 100 Year Floodplain

  Yes
- Outside 500 Year Floodplain

  Yes
ELECTRICAL POWER
- Aggregate Power Availability

  5MW
- Utility Upgrade Capacity

  12MW+ (Phased)
- UPS Redundancy

  2N
- PDU Redundancy

  No
- Generator Redundancy

  N+1
- Concurrently Maintainable Electric

  Yes
MECHANICAL/COOLING
- Mechanical Tier Equivalent

  2N
- Cooling Type

  Chilled Water
- Cooling Method

  Liquid / Air Hybrid
- Chiller Redundancy

  N+1
- Variable Frequency Drives

  Yes
- Economizers

  Yes
GENERAL FEATURES
- Protected Exterior (Fencing, Bollards, Standoffs)

  Yes
- Support Operation Center (SOC)

  Yes
- Advanced Customer Portal

  Yes
- Available Conference & Office Space

  Yes

The DDC® Difference

Dynamic Density Control

ScaleMatrix delivers real Return-on-Investment (ROI) through the use of their revolutionary Dynamic Density Control® (DDC) platform. Clients enjoy hosting within the most secure, flexible, and future-proofed colocation sites in North America, while their investment made in IT hardware and technology goes further and last longer when colocated in these advanced Data Centers. With guaranteed environmental control and surgical temperature and airflow management, servers perform better, last longer, and provide a better return on overall investment than in any other Data Center.

Want to deploy this revolutionary data center platform within your own facility?

Connect with a DDC specialist
